Cormidi > CMF Tracked Carrier
CMF MULTI-FUNCTION
SKID STEER
Depending on the model, the CMF Series with EVO Loader has a maximum 1170 kg tipping capacity with counterweights and is one of the highest capacity models for its width.
The super-silenced hood makes the machine quiet while adding to its look and feel. The dashboard has various functions, such as a digital display, fuel level, signal indicator lights, electric start, horn, joystick control, and power controller, making the CMF series an unrivalled product.
It’s part of a multi-function category designed to make work easier, allowing you to use multiple body styles on one track base with options for:
-
ML EVO Loader Arm with quick attachment plate
Standard Dumper, Dumper with options for Hi Tip, Swivel & Self-Loading
Pallet Carrier
Flat Vessel with three-way tipping
Concrete Mix with options for Swivel & Self-Loading
Also an 11 metre MEWP attachment
-
Engine KUBOTA type: D1105 D1305 * dependent on model
Fuel: Diesel
Power in Kw / HP 18,5 / 25,1
Machine width in mm 865 mm 895 mm 945 mm * dependent on model
Crawler width in mm 200 mm - 230 mm* dependent on model
2 hydrostatic transmissions with closed circuit
Transmissions with joystick control
Travel speed fine regulator
Ergonomic and reinforced travel levers
Hydraulic oil cooler with electrical fan
Auxiliary hydraulic circuit: flow in ltr/min 26 lt/min 27lt/min
Auxiliary hydraulic circuit: pressure in bars 185 bars * standard
Auxiliary hydraulic circuit with Hi Flow: flow in ltr/min 52 lt/ 58 lt/min *optional
Auxiliary hydraulic circuit with Hi Flow: pressure in bars 280 bars * optional
2 x double acting hydraulic lines with a single lever
3 x double acting hydraulic lines with three levers * optional
Quick couplings for connection of work equipment
Floating position for mini loader electrically powered *optional
Rubber lever handles
Hydraulic oil level indicator visible from the outside
Parking brake due to lack of pressure or by electric control
Soundproof engine hood with lock
Dual-cartridge air filter with clogging indicator
Engine safety indicator with buzzer
Reinforced chassis
Load and tension rollers with grease nipples
Double rocking rollers
Reinforced long-life crawlers
Battery isolator switch under the engine hood
Reinforced 55 Amp / h battery
CORMIDI digital dashboard
Horn
12 volt external socket
Foldable operator platform
Lifting and lashing eyes
Synthetic materials dashboard
Acid resistant stickers
Closed and waterproof document box
Lockable fuel tank cap
Please look at the links below for information on the rated operating capacity.
Pricing on application due to options
Free Delivery (Mainland UK)!
